The Edge-on Galaxy Database

The Edge-on Galaxy candidates in Pan-STARRS1 survey dr2 found by ANN

Examples

The request returns a single object.

Candidate 1449_044.0

149.776843 +5.991321
A : B 6.08 : 1.79
e 0.705
B/A 0.295
A/B 3.39
PA 32.6
r (mag) 15.99
ANN Votes
1.000 1.000 1.000 1.000 1.000
Visual inspection
Edge-on1
Nearly Edge-on2
Not Edge-on0
SExtractor photometry. Ver 2
Band J2000 A B Ell B/A PA
g 149.776823 +5.991409 5.890 ± 0.041 0.881 ± 0.006 0.850 0.150 33.46
r 149.776816 +5.991432 7.605 ± 0.024 1.185 ± 0.004 0.844 0.156 34.56
i 149.776806 +5.991457 7.188 ± 0.023 1.090 ± 0.003 0.848 0.152 34.32
z 149.776793 +5.991475 6.079 ± 0.028 0.951 ± 0.004 0.844 0.156 34.17
y 149.776781 +5.991478 3.641 ± 0.028 0.788 ± 0.006 0.784 0.216 33.11
Band kKron magAuto kPetro magPetro
g 5.30 17.341 ± 0.008 8.58 17.351 ± 0.011
r 3.95 16.500 ± 0.004 6.60 16.477 ± 0.005
i 3.97 16.002 ± 0.004 6.60 15.974 ± 0.005
z 4.38 15.706 ± 0.005 7.26 15.679 ± 0.007
y 5.82 15.505 ± 0.009 10.56 15.505 ± 0.015
1449_044.0_contour_g1449_044.0_contour_r1449_044.0_contour_i1449_044.0_contour_z1449_044.0_contour_y
StatMorp non-parametric morphology
Band Ellcentroid a/bcentroid Ellasymmetry a/basymmetry RPetro Rhalf R20 R50 R80 Gini M20 C A S
g 0.852 6.753 0.846 6.479 26.899 15.389 2.184 4.516 8.437 0.576 -0.546 2.934 0.032 -0.024
r 0.841 6.279 0.837 6.125 27.220 14.982 2.883 6.860 17.506 0.651 -0.524 3.917 0.381 0.078
i 0.844 6.391 0.843 6.360 26.620 14.211 2.301 5.089 11.082 0.664 -0.495 3.413 0.311 0.112
z 0.843 6.374 0.842 6.344 25.130 13.424 2.010 4.522 9.033 0.639 -0.505 3.264 0.190 0.056
y 0.833 5.988 0.830 5.890 22.620 11.564 1.925 4.336 8.342 0.574 -0.516 3.184 0.032 0.052
SExtractor photometry. Ver 1
Band J2000 A B Ell B/A PA
g 149.776928 +5.991316 5.311 ± 0.033 1.735 ± 0.009 0.673 0.327 30.98
r 149.776762 +5.991199 6.922 ± 0.020 1.877 ± 0.005 0.729 0.271 33.68
i 149.776795 +5.991269 6.598 ± 0.019 1.800 ± 0.004 0.727 0.273 33.27
z 149.776851 +5.991343 5.594 ± 0.023 1.709 ± 0.006 0.695 0.305 32.39
y 149.776779 +5.991487 3.642 ± 0.028 0.784 ± 0.006 0.785 0.215 33.11
Band kKron magAuto kPetro magPetro
g 4.37 17.227 ± 0.008 7.92 17.308 ± 0.014
r 3.64 16.348 ± 0.004 5.94 16.340 ± 0.005
i 3.62 15.855 ± 0.004 5.94 15.843 ± 0.005
z 3.92 15.564 ± 0.005 6.60 15.556 ± 0.008
y 5.83 15.504 ± 0.009 10.56 15.504 ± 0.015
1449_044.0
