The Edge-on Galaxy Database

The Edge-on Galaxy candidates in Pan-STARRS1 survey dr2 found by ANN

Examples

The request returns a single object.

Candidate 1454_013.0

170.482654 +4.537104
A : B 7.43 : 1.13
e 0.849
B/A 0.151
A/B 6.61
PA 140.2
r (mag) 15.92
ANN Votes
1.000 1.000 1.000 1.000 1.000
Visual inspection
Edge-on2
Nearly Edge-on1
Not Edge-on0
SExtractor photometry. Ver 2
Band J2000 A B Ell B/A PA
g 170.482651 +4.537108 7.761 ± 0.033 1.116 ± 0.005 0.856 0.144 140.25
r 170.482571 +4.537163 7.594 ± 0.025 1.235 ± 0.004 0.837 0.163 140.18
i 170.482660 +4.537097 8.363 ± 0.013 1.432 ± 0.003 0.829 0.171 140.35
z 170.482612 +4.537144 7.410 ± 0.022 1.137 ± 0.003 0.847 0.153 140.25
y 170.482634 +4.537056 4.566 ± 0.044 0.715 ± 0.007 0.843 0.157 140.86
Band kKron magAuto kPetro magPetro
g 4.28 16.758 ± 0.006 6.60 16.759 ± 0.007
r 3.97 16.049 ± 0.004 6.60 16.058 ± 0.006
i 3.59 15.640 ± 0.002 5.94 15.623 ± 0.003
z 4.04 15.392 ± 0.004 6.60 15.382 ± 0.005
y 5.95 15.222 ± 0.012 9.24 15.232 ± 0.017
1454_013.0_contour_g1454_013.0_contour_r1454_013.0_contour_i1454_013.0_contour_z1454_013.0_contour_y
StatMorp non-parametric morphology
Band Ellcentroid a/bcentroid Ellasymmetry a/basymmetry RPetro Rhalf R20 R50 R80 Gini M20 C A S
g 0.845 6.436 0.844 6.430 24.236 12.561 3.150 7.103 12.859 0.510 -1.322 3.054 -0.247 -0.098
r 0.839 6.202 0.839 6.200 24.513 11.994 2.985 6.863 12.778 0.547 -1.506 3.158 -0.123 0.001
i 0.841 6.291 0.841 6.288 23.039 12.206 2.952 6.975 13.424 0.562 -1.524 3.289 -0.030 0.073
z 0.843 6.369 0.842 6.335 22.895 12.035 2.881 6.869 13.398 0.561 -1.535 3.337 -0.120 -0.011
y 0.842 6.331 0.841 6.308 21.776 11.286 2.463 5.809 10.580 0.474 -1.305 3.165 -0.813 -0.519
SExtractor photometry. Ver 1
Band J2000 A B Ell B/A PA
g 170.482651 +4.537108 7.761 ± 0.033 1.116 ± 0.005 0.856 0.144 140.25
r 170.482571 +4.537163 7.594 ± 0.025 1.235 ± 0.004 0.837 0.163 140.18
i 170.482660 +4.537097 8.363 ± 0.013 1.432 ± 0.003 0.829 0.171 140.35
z 170.482612 +4.537144 7.410 ± 0.022 1.137 ± 0.003 0.847 0.153 140.25
y 170.482634 +4.537056 4.566 ± 0.044 0.715 ± 0.007 0.843 0.157 140.86
Band kKron magAuto kPetro magPetro
g 4.28 16.758 ± 0.006 6.60 16.759 ± 0.007
r 3.97 16.049 ± 0.004 6.60 16.058 ± 0.006
i 3.59 15.640 ± 0.002 5.94 15.623 ± 0.003
z 4.04 15.392 ± 0.004 6.60 15.382 ± 0.005
y 5.95 15.222 ± 0.012 9.24 15.232 ± 0.017
1454_013.0
