The Edge-on Galaxy Database

The Edge-on Galaxy candidates in Pan-STARRS1 survey dr2 found by ANN

Examples

The request returns a single object.

Candidate 1965_006.0

158.884926 +27.984724
A : B 6.00 : 0.78
e 0.869
B/A 0.131
A/B 7.66
PA 55.0
r (mag) 16.45
ANN Votes
0.996 0.996 1.000 1.000 1.000
Visual inspection
Edge-on1
Nearly Edge-on2
Not Edge-on0
Problematic 2
SExtractor photometry. Ver 2
Band J2000 A B Ell B/A PA
g 158.884903 +27.984723 5.931 ± 0.031 0.764 ± 0.004 0.871 0.129 54.49
r 158.884913 +27.984713 6.127 ± 0.020 0.881 ± 0.003 0.856 0.144 54.70
i 158.884914 +27.984733 6.338 ± 0.020 0.900 ± 0.003 0.858 0.142 54.64
z 158.884920 +27.984724 5.814 ± 0.024 0.865 ± 0.004 0.851 0.149 54.66
y 158.884956 +27.984750 4.646 ± 0.036 0.655 ± 0.005 0.859 0.141 54.59
Band kKron magAuto kPetro magPetro
g 4.64 17.347 ± 0.007 6.60 17.303 ± 0.009
r 4.07 16.733 ± 0.004 5.94 16.694 ± 0.005
i 3.97 16.356 ± 0.004 5.94 16.320 ± 0.005
z 4.30 16.144 ± 0.005 6.60 16.109 ± 0.007
y 5.56 15.908 ± 0.010 9.24 15.834 ± 0.013
1965_006.0_contour_g1965_006.0_contour_r1965_006.0_contour_i1965_006.0_contour_z1965_006.0_contour_y
StatMorp non-parametric morphology
Band Ellcentroid a/bcentroid Ellasymmetry a/basymmetry RPetro Rhalf R20 R50 R80 Gini M20 C A S
g 0.649 2.852 0.658 2.927 15.431 6.610 2.590 4.334 9.609 0.623 -0.627 2.847 0.567 -0.800
r 0.675 3.077 0.671 3.044 16.061 6.753 2.460 4.516 9.981 0.713 -0.687 3.041 0.925 -0.361
i 0.682 3.147 0.673 3.062 16.584 7.137 2.198 4.824 10.572 0.724 -0.698 3.410 0.913 -0.422
z 0.676 3.090 0.671 3.039 16.169 7.283 2.517 4.895 10.082 0.678 -0.682 3.013 0.817 -0.383
y 0.692 3.246 0.690 3.223 15.626 5.954 2.726 3.527 4.990 0.625 -0.568 1.313 0.651 0.060
SExtractor photometry. Ver 1
Band J2000 A B Ell B/A PA
g 158.885135 +27.984855 3.000 ± 0.020 0.781 ± 0.006 0.740 0.260 52.72
r 158.881309 +27.983729 5.294 ± 0.016 1.343 ± 0.005 0.746 0.254 82.74
i 158.881288 +27.983729 5.011 ± 0.013 1.314 ± 0.005 0.738 0.262 83.50
z 158.881303 +27.983743 4.208 ± 0.018 1.206 ± 0.006 0.714 0.286 88.25
y 158.885001 +27.984746 4.588 ± 0.037 0.674 ± 0.005 0.853 0.147 54.56
Band kKron magAuto kPetro magPetro
g 6.14 17.624 ± 0.010 10.56 17.560 ± 0.014
r 3.50 17.005 ± 0.004 5.94 16.945 ± 0.007
i 3.50 16.653 ± 0.004 5.94 16.609 ± 0.006
z 3.59 16.599 ± 0.006 6.60 16.541 ± 0.010
y 5.53 15.911 ± 0.010 9.24 15.836 ± 0.013
1965_006.0
