The Edge-on Galaxy Database

The Edge-on Galaxy candidates in Pan-STARRS1 survey dr2 found by ANN

Examples

The request returns a single object.

Candidate 2001_036.0

322.681449 +29.254446
A : B 4.75 : 1.07
e 0.776
B/A 0.224
A/B 4.46
PA 117.6
r (mag) 16.32
ANN Votes
0.198 0.995 0.995 1.000 1.000
Visual inspection
Edge-on0
Nearly Edge-on1
Not Edge-on3
SExtractor photometry. Ver 2
Band J2000 A B Ell B/A PA
g 322.681548 +29.254419 4.729 ± 0.019 0.965 ± 0.004 0.796 0.204 116.92
r 322.681463 +29.254436 4.532 ± 0.014 1.054 ± 0.003 0.767 0.233 117.61
i 322.681455 +29.254419 4.383 ± 0.012 1.024 ± 0.003 0.766 0.234 118.20
z 322.681453 +29.254406 3.928 ± 0.016 0.964 ± 0.004 0.755 0.245 118.79
y 322.681357 +29.254454 2.967 ± 0.024 0.690 ± 0.005 0.767 0.233 118.27
Band kKron magAuto kPetro magPetro
g 3.76 17.601 ± 0.005 5.94 17.599 ± 0.007
r 3.62 16.901 ± 0.004 5.94 16.889 ± 0.005
i 3.50 16.421 ± 0.003 5.94 16.418 ± 0.005
z 3.64 16.176 ± 0.005 5.94 16.170 ± 0.007
y 4.51 15.981 ± 0.010 7.92 16.027 ± 0.017
2001_036.0_contour_g2001_036.0_contour_r2001_036.0_contour_i2001_036.0_contour_z2001_036.0_contour_y
StatMorp non-parametric morphology
Band Ellcentroid a/bcentroid Ellasymmetry a/basymmetry RPetro Rhalf R20 R50 R80 Gini M20 C A S
g 0.779 4.525 0.779 4.522 12.857 9.396 2.278 5.245 9.541 0.374 -0.906 3.111 -0.004 -0.050
r 0.764 4.246 0.764 4.246 12.416 9.226 1.923 4.675 8.768 0.415 -0.995 3.295 -0.044 -0.012
i 0.764 4.236 0.764 4.237 11.781 8.686 1.768 4.394 8.298 0.424 -1.029 3.357 -0.009 -0.017
z 0.752 4.030 0.752 4.031 11.649 8.274 1.604 3.886 7.542 0.460 -1.026 3.361 -0.109 -0.049
y 0.748 3.967 0.750 3.993 11.162 7.763 1.654 4.069 8.353 0.480 -1.089 3.516 -0.111 -0.088
SExtractor photometry. Ver 1
Band J2000 A B Ell B/A PA
g 322.681548 +29.254419 4.729 ± 0.019 0.965 ± 0.004 0.796 0.204 116.92
r 322.681463 +29.254436 4.532 ± 0.014 1.054 ± 0.003 0.767 0.233 117.61
i 322.681404 +29.254450 4.295 ± 0.012 1.026 ± 0.003 0.761 0.239 118.61
z 322.681453 +29.254406 3.928 ± 0.016 0.964 ± 0.004 0.755 0.245 118.79
y 322.681357 +29.254454 2.967 ± 0.024 0.690 ± 0.005 0.767 0.233 118.27
Band kKron magAuto kPetro magPetro
g 3.76 17.601 ± 0.005 5.94 17.599 ± 0.007
r 3.62 16.901 ± 0.004 5.94 16.889 ± 0.005
i 3.50 16.421 ± 0.003 5.94 16.419 ± 0.005
z 3.64 16.176 ± 0.005 5.94 16.170 ± 0.007
y 4.51 15.981 ± 0.010 7.92 16.027 ± 0.017
2001_036.0
