The Edge-on Galaxy Database

The Edge-on Galaxy candidates in Pan-STARRS1 survey dr2 found by ANN

Examples

The request returns a single object.

Candidate 2212_060.0

293.490901 +42.718199
A : B 4.92 : 1.44
e 0.707
B/A 0.293
A/B 3.41
PA 140.5
r (mag) 15.88
ANN Votes
0.081 0.081 0.137 0.137 0.799
Visual inspection
Edge-on0
Nearly Edge-on1
Not Edge-on3
SExtractor photometry. Ver 2
Band J2000 A B Ell B/A PA
g 293.490862 +42.718226 3.994 ± 0.014 1.115 ± 0.004 0.721 0.279 141.10
r 293.490894 +42.718209 4.037 ± 0.010 1.213 ± 0.003 0.699 0.301 141.49
i 293.490871 +42.718204 4.204 ± 0.009 1.272 ± 0.003 0.697 0.303 141.11
z 293.490864 +42.718215 3.850 ± 0.011 1.175 ± 0.003 0.695 0.305 141.20
y 293.490846 +42.718216 3.523 ± 0.012 1.125 ± 0.004 0.681 0.319 141.61
Band kKron magAuto kPetro magPetro
g 4.01 16.707 ± 0.004 6.60 16.678 ± 0.005
r 3.79 15.803 ± 0.003 6.60 15.765 ± 0.004
i 3.63 15.287 ± 0.002 5.94 15.245 ± 0.003
z 3.96 14.976 ± 0.003 6.60 14.934 ± 0.004
y 4.02 14.745 ± 0.004 6.60 14.712 ± 0.005
2212_060.0_contour_g2212_060.0_contour_r2212_060.0_contour_i2212_060.0_contour_z2212_060.0_contour_y
StatMorp non-parametric morphology
Band Ellcentroid a/bcentroid Ellasymmetry a/basymmetry RPetro Rhalf R20 R50 R80 Gini M20 C A S
g 0.719 3.561 0.716 3.517 20.966 49.004 1.729 4.951 12.242 0.831 -0.949 4.251 -0.444 -0.071
r 0.703 3.366 0.703 3.368 12.841 26.310 1.356 3.376 7.123 0.882 -1.988 3.602 -0.627 -0.064
i 0.702 3.354 0.702 3.356 12.478 17.861 1.371 3.354 7.027 0.867 -1.995 3.548 -0.430 -0.042
z 0.702 3.352 0.702 3.353 13.044 14.103 1.401 3.480 7.282 0.862 -2.081 3.579 -0.302 -0.030
y 0.693 3.255 0.693 3.254 12.442 11.280 1.397 3.364 6.699 0.824 -1.969 3.404 -0.207 -0.010
SExtractor photometry. Ver 1
Band J2000 A B Ell B/A PA
g 293.490862 +42.718226 3.994 ± 0.014 1.115 ± 0.004 0.721 0.279 141.10
r 293.490894 +42.718209 4.037 ± 0.010 1.213 ± 0.003 0.699 0.301 141.49
i 293.490871 +42.718204 4.204 ± 0.009 1.272 ± 0.003 0.697 0.303 141.11
z 293.490864 +42.718215 3.850 ± 0.011 1.175 ± 0.003 0.695 0.305 141.20
y 293.490846 +42.718216 3.523 ± 0.012 1.125 ± 0.004 0.681 0.319 141.61
Band kKron magAuto kPetro magPetro
g 4.01 16.707 ± 0.004 6.60 16.678 ± 0.005
r 3.79 15.803 ± 0.003 6.60 15.765 ± 0.004
i 3.63 15.287 ± 0.002 5.94 15.245 ± 0.003
z 3.96 14.976 ± 0.003 6.60 14.934 ± 0.004
y 4.02 14.745 ± 0.004 6.60 14.712 ± 0.005
2212_060.0
