The Edge-on Galaxy Database

The Edge-on Galaxy candidates in Pan-STARRS1 survey dr2 found by ANN

Examples

The request returns a single object.

Candidate 0802_060.0

27.839519 -21.452378
A : B 7.26 : 1.93
e 0.735
B/A 0.265
A/B 3.77
PA 41.0
r (mag) 15.13
ANN Votes
0.000 0.000 0.519 0.519 0.963
Visual inspection
Edge-on0
Nearly Edge-on0
Not Edge-on3
SExtractor photometry. Ver 2
Band J2000 A B Ell B/A PA
g 27.839548 -21.452300 6.719 ± 0.016 1.726 ± 0.004 0.743 0.257 40.78
r 27.839490 -21.452402 5.966 ± 0.013 1.613 ± 0.004 0.730 0.270 40.78
i 27.839499 -21.452402 6.042 ± 0.010 1.753 ± 0.003 0.710 0.290 40.54
z 27.839499 -21.452416 5.651 ± 0.011 1.657 ± 0.003 0.707 0.293 40.57
y 27.839452 -21.452488 4.718 ± 0.015 1.377 ± 0.004 0.708 0.292 40.76
Band kKron magAuto kPetro magPetro
g 3.78 15.811 ± 0.002 6.60 15.802 ± 0.004
r 3.82 15.164 ± 0.002 6.60 15.143 ± 0.003
i 3.60 14.839 ± 0.002 5.94 14.809 ± 0.002
z 3.66 14.586 ± 0.002 5.94 14.556 ± 0.003
y 4.27 14.348 ± 0.004 7.26 14.346 ± 0.006
0802_060.0_contour_g0802_060.0_contour_r0802_060.0_contour_i0802_060.0_contour_z0802_060.0_contour_y
StatMorp non-parametric morphology
Band Ellcentroid a/bcentroid Ellasymmetry a/basymmetry RPetro Rhalf R20 R50 R80 Gini M20 C A S
g 0.745 3.914 0.745 3.929 21.079 9.413 2.187 5.184 9.814 0.548 -1.966 3.260 0.062 0.029
r 0.739 3.836 0.740 3.845 19.696 8.649 2.038 4.904 9.629 0.561 -1.992 3.372 0.068 0.043
i 0.729 3.688 0.729 3.694 18.554 8.292 1.972 4.704 9.223 0.553 -1.984 3.350 0.013 0.014
z 0.725 3.635 0.725 3.643 17.926 7.914 1.930 4.526 8.832 0.555 -1.966 3.303 0.001 0.013
y 0.723 3.616 0.724 3.624 16.745 7.592 1.911 4.453 8.673 0.535 -1.925 3.284 -0.139 -0.045
SExtractor photometry. Ver 1
Band J2000 A B Ell B/A PA
g 27.839548 -21.452300 6.719 ± 0.016 1.726 ± 0.004 0.743 0.257 40.78
r 27.839490 -21.452402 5.966 ± 0.013 1.613 ± 0.004 0.730 0.270 40.78
i 27.839499 -21.452402 6.042 ± 0.010 1.753 ± 0.003 0.710 0.290 40.54
z 27.839499 -21.452416 5.651 ± 0.011 1.657 ± 0.003 0.707 0.293 40.57
y 27.839452 -21.452488 4.718 ± 0.015 1.377 ± 0.004 0.708 0.292 40.76
Band kKron magAuto kPetro magPetro
g 3.78 15.811 ± 0.002 6.60 15.802 ± 0.004
r 3.82 15.164 ± 0.002 6.60 15.143 ± 0.003
i 3.60 14.839 ± 0.002 5.94 14.809 ± 0.002
z 3.66 14.586 ± 0.002 5.94 14.556 ± 0.003
y 4.27 14.348 ± 0.004 7.26 14.346 ± 0.006
0802_060.0
